Categorical

Overview

Categorical data represents values as named groups, stages, or classes rather than continuous measurements, and it appears in nearly every analytical workflow. Categorical charts turn these labels into structure, making proportions, rankings, and before/after differences easy to interpret. In operations, marketing, product analytics, and quality engineering, these visuals help teams prioritize decisions faster than raw tables. The category focuses on practical chart forms that emphasize composition, ordering, and change.

The unifying ideas are part-to-whole composition, ordered comparison, and delta tracking across labeled groups. Composition views highlight how categories split a total; ordered views reveal rank and long-tail effects; change views show increases, decreases, and net outcomes across steps. Together, these perspectives support exploratory analysis and executive reporting, especially when analysts need to explain both magnitude and direction. Many of these charts also encode business process flow, where category order is as important as value size.

These tools are implemented with Matplotlib, the core plotting library in the Python scientific stack. Matplotlib provides low-level control over marks, axes, color maps, and annotation, which makes it well-suited for specialized business visuals such as funnel, pareto, and waterfall charts. The functions in this category expose those capabilities through spreadsheet-friendly interfaces while returning standard figure objects for Python workflows.

For composition and stage views, DONUT and FUNNEL summarize how totals are distributed across categories or process steps. Donut charts emphasize share of whole with a compact circular form, while funnel charts emphasize ordered drop-off through sequential stages such as awareness-to-conversion pipelines. Used together, they distinguish static composition from directional progression in the same dataset family.

For ranked and pointwise comparisons, DOT_PLOT, STEM, and PARETO_CHART focus attention on ordering and concentration. Dot and stem/lollipop forms reduce chart ink and make individual category values easy to compare, especially when labels are long or categories are numerous. Pareto charts add a cumulative line to sorted bars, helping analysts identify the small subset of categories that explain most outcomes (the common 80/20 diagnostic pattern).

For before/after and contribution analysis, DUMBBELL, SLOPE, and WATERFALL make change explicit. Dumbbell and slope charts connect paired values per category to show direction and magnitude of movement between two states (for example baseline vs current period). Waterfall charts decompose a running total into positive and negative contributions, clarifying how individual components build to a final result. These are especially useful in financial bridge analysis, KPI decomposition, and scenario reviews.

Figure 1: Categorical chart concepts: a composition view (donut) and a contribution view (waterfall) for the same business context.

DONUT

Create a donut chart from data.

Excel Usage

=DONUT(data, title, color_map, hole_size, legend)

• data (list[list], required): Input data (Labels, Values).
• title (str, optional, default: null): Chart title.
• color_map (str, optional, default: “viridis”): Color map for slices.
• hole_size (float, optional, default: 0.5): Size of the donut hole (0-1).
• legend (str, optional, default: “true”): Show legend.

Returns (object): Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).

Example 1: Simple donut chart with 3 categories

Inputs:

data
A	30
B	50
C	20

Excel formula:

=DONUT({"A",30;"B",50;"C",20})

Expected output:

"chart"

Example 2: Donut chart with title and legend

Inputs:

data		title	legend
Q1	100	Quarterly Sales	true
Q2	150
Q3	120
Q4	180

Excel formula:

=DONUT({"Q1",100;"Q2",150;"Q3",120;"Q4",180}, "Quarterly Sales", "true")

Expected output:

"chart"

Example 3: Donut with plasma colormap and small hole

Inputs:

data		color_map	hole_size
Category A	25	plasma	0.3
Category B	35
Category C	40

Excel formula:

=DONUT({"Category A",25;"Category B",35;"Category C",40}, "plasma", 0.3)

Expected output:

"chart"

Example 4: Donut with large center hole

Inputs:

data		hole_size
Item 1	60	0.7
Item 2	40

Excel formula:

=DONUT({"Item 1",60;"Item 2",40}, 0.7)

Expected output:

"chart"

Python Code

Show Code

import sys
import matplotlib
IS_PYODIDE = sys.platform == "emscripten"
if IS_PYODIDE:
    matplotlib.use('Agg')
import matplotlib.pyplot as plt
import io
import base64
import numpy as np

def donut(data, title=None, color_map='viridis', hole_size=0.5, legend='true'):
    """
    Create a donut chart from data.

    See: https://matplotlib.org/stable/gallery/pie_and_polar_charts/pie_and_donut_labels.html

    This example function is provided as-is without any representation of accuracy.

    Args:
        data (list[list]): Input data (Labels, Values).
        title (str, optional): Chart title. Default is None.
        color_map (str, optional): Color map for slices. Valid options: Viridis, Plasma, Inferno, Magma, Cividis. Default is 'viridis'.
        hole_size (float, optional): Size of the donut hole (0-1). Default is 0.5.
        legend (str, optional): Show legend. Valid options: True, False. Default is 'true'.

    Returns:
        object: Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).
    """
    def to2d(x):
        return [[x]] if not isinstance(x, list) else x

    try:
        data = to2d(data)

        if not isinstance(data, list) or len(data) < 1:
            return "Error: Data must be a non-empty list"

        # Extract labels and values
        labels = []
        values = []
        for row in data:
            if not isinstance(row, list) or len(row) < 2:
                continue
            try:
                labels.append(str(row[0]))
                values.append(float(row[1]))
            except (ValueError, TypeError):
                continue

        if len(labels) == 0 or len(values) == 0:
            return "Error: No valid data rows found"

        if any(v < 0 for v in values):
            return "Error: Values must be non-negative"

        # Create figure
        fig, ax = plt.subplots(figsize=(8, 6))

        # Create donut chart
        wedges, texts, autotexts = ax.pie(
            values,
            labels=labels,
            autopct='%1.1f%%',
            startangle=90,
            wedgeprops=dict(width=1-hole_size),
            colors=plt.cm.get_cmap(color_map)(np.linspace(0, 1, len(values)))
        )

        # Set title
        if title:
            ax.set_title(title)

        # Handle legend
        if legend == "true":
            ax.legend(labels, loc="best")

        # Equal aspect ratio ensures circular shape
        ax.axis('equal')

        if IS_PYODIDE:
            buf = io.BytesIO()
            plt.savefig(buf, format='png', bbox_inches='tight')
            plt.close(fig)
            buf.seek(0)
            img_base64 = base64.b64encode(buf.read()).decode('utf-8')
        else:
            return fig
    except Exception as e:
        return f"Error: {str(e)}"

Online Calculator

data *

Input data (Labels, Values).

title

Chart title.

color_map Optional Viridis Plasma Inferno Magma Cividis

Color map for slices.

hole_size

Size of the donut hole (0-1).

legend Optional True False

Show legend.

---

DOT_PLOT

Create a Cleveland dot plot from data.

Excel Usage

=DOT_PLOT(data, title, xlabel, ylabel, plot_color, marker, legend)

• data (list[list], required): Input data (Labels, Values).
• title (str, optional, default: null): Chart title.
• xlabel (str, optional, default: null): Label for X-axis.
• ylabel (str, optional, default: null): Label for Y-axis.
• plot_color (str, optional, default: “blue”): Dot color.
• marker (str, optional, default: “o”): Marker style.
• legend (str, optional, default: “false”): Show legend.

Returns (object): Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).

Example 1: Simple Cleveland dot plot

Inputs:

data
Category A	25
Category B	40
Category C	15
Category D	30

Excel formula:

=DOT_PLOT({"Category A",25;"Category B",40;"Category C",15;"Category D",30})

Expected output:

"chart"

Example 2: Dot plot with custom labels

Inputs:

data		title	xlabel	ylabel
Item 1	10	Item Comparison	Values	Items
Item 2	20
Item 3	15

Excel formula:

=DOT_PLOT({"Item 1",10;"Item 2",20;"Item 3",15}, "Item Comparison", "Values", "Items")

Expected output:

"chart"

Example 3: Dot plot with square markers

Inputs:

data		plot_color	marker
A	5	red	s
B	10
C	8

Excel formula:

=DOT_PLOT({"A",5;"B",10;"C",8}, "red", "s")

Expected output:

"chart"

Example 4: Dot plot with legend and triangle markers

Inputs:

data		legend	marker	plot_color
Group 1	50	true	^	green
Group 2	75
Group 3	60

Excel formula:

=DOT_PLOT({"Group 1",50;"Group 2",75;"Group 3",60}, "true", "^", "green")

Expected output:

"chart"

Python Code

Show Code

import sys
import matplotlib
IS_PYODIDE = sys.platform == "emscripten"
if IS_PYODIDE:
    matplotlib.use('Agg')
import matplotlib.pyplot as plt
import io
import base64
import numpy as np

def dot_plot(data, title=None, xlabel=None, ylabel=None, plot_color='blue', marker='o', legend='false'):
    """
    Create a Cleveland dot plot from data.

    See: https://matplotlib.org/stable/api/_as_gen/matplotlib.axes.Axes.scatter.html

    This example function is provided as-is without any representation of accuracy.

    Args:
        data (list[list]): Input data (Labels, Values).
        title (str, optional): Chart title. Default is None.
        xlabel (str, optional): Label for X-axis. Default is None.
        ylabel (str, optional): Label for Y-axis. Default is None.
        plot_color (str, optional): Dot color. Valid options: Blue, Green, Red, Cyan, Magenta, Yellow, Black, White. Default is 'blue'.
        marker (str, optional): Marker style. Valid options: None, Point, Pixel, Circle, Square, Triangle Down, Triangle Up. Default is 'o'.
        legend (str, optional): Show legend. Valid options: True, False. Default is 'false'.

    Returns:
        object: Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).
    """
    def to2d(x):
        return [[x]] if not isinstance(x, list) else x

    try:
        data = to2d(data)

        if not isinstance(data, list) or len(data) < 1:
            return "Error: Data must be a non-empty list"

        # Extract labels and values
        labels = []
        values = []
        for row in data:
            if not isinstance(row, list) or len(row) < 2:
                continue
            try:
                labels.append(str(row[0]))
                values.append(float(row[1]))
            except (ValueError, TypeError):
                continue

        if len(labels) == 0 or len(values) == 0:
            return "Error: No valid data rows found"

        # Create figure
        fig, ax = plt.subplots(figsize=(8, 6))

        # Create dot plot (Cleveland style)
        y_pos = np.arange(len(labels))

        # Draw lines from 0 to value
        for i, val in enumerate(values):
            ax.plot([0, val], [i, i], 'k-', linewidth=1, alpha=0.5)

        # Draw dots
        ax.scatter(values, y_pos, color=plot_color, marker=marker, s=100, zorder=3)

        # Set labels
        ax.set_yticks(y_pos)
        ax.set_yticklabels(labels)

        if title:
            ax.set_title(title)
        if xlabel:
            ax.set_xlabel(xlabel)
        if ylabel:
            ax.set_ylabel(ylabel)

        # Handle legend
        if legend == "true":
            ax.legend(['Data'], loc="best")

        ax.grid(axis='x', alpha=0.3)
        plt.tight_layout()

        if IS_PYODIDE:
            buf = io.BytesIO()
            plt.savefig(buf, format='png', bbox_inches='tight')
            plt.close(fig)
            buf.seek(0)
            img_base64 = base64.b64encode(buf.read()).decode('utf-8')
        else:
            return fig
    except Exception as e:
        return f"Error: {str(e)}"

Online Calculator

data *

Input data (Labels, Values).

title

Chart title.

xlabel

Label for X-axis.

ylabel

Label for Y-axis.

plot_color Optional Blue Green Red Cyan Magenta Yellow Black White

Dot color.

marker Optional None Point Pixel Circle Square Triangle Down Triangle Up

Marker style.

legend Optional True False

Show legend.

---

DUMBBELL

Create a dumbbell plot (range comparison) from data.

Excel Usage

=DUMBBELL(data, title, xlabel, ylabel, color_start, color_end, grid, legend)

• data (list[list], required): Input data (Labels, Start, End).
• title (str, optional, default: null): Chart title.
• xlabel (str, optional, default: null): Label for X-axis.
• ylabel (str, optional, default: null): Label for Y-axis.
• color_start (str, optional, default: “blue”): Start color.
• color_end (str, optional, default: “red”): End color.
• grid (str, optional, default: “true”): Show grid lines.
• legend (str, optional, default: “false”): Show legend.

Returns (object): Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).

Example 1: Simple dumbbell plot

Inputs:

data
Product A	20	35
Product B	15	40
Product C	25	30

Excel formula:

=DUMBBELL({"Product A",20,35;"Product B",15,40;"Product C",25,30})

Expected output:

"chart"

Example 2: Dumbbell plot with labels and grid

Inputs:

data			title	xlabel	ylabel	grid
Q1	100	150	Quarterly Performance	Sales	Quarter	true
Q2	120	180
Q3	110	160

Excel formula:

=DUMBBELL({"Q1",100,150;"Q2",120,180;"Q3",110,160}, "Quarterly Performance", "Sales", "Quarter", "true")

Expected output:

"chart"

Example 3: Dumbbell with custom colors

Inputs:

data			color_start	color_end
Before	10	25	black	orange
After	15	30

Excel formula:

=DUMBBELL({"Before",10,25;"After",15,30}, "black", "orange")

Expected output:

"chart"

Example 4: Dumbbell plot with legend

Inputs:

data			legend	grid
Item 1	5	15	true	true
Item 2	8	20
Item 3	12	22

Excel formula:

=DUMBBELL({"Item 1",5,15;"Item 2",8,20;"Item 3",12,22}, "true", "true")

Expected output:

"chart"

Python Code

Show Code

import sys
import matplotlib
IS_PYODIDE = sys.platform == "emscripten"
if IS_PYODIDE:
    matplotlib.use('Agg')
import matplotlib.pyplot as plt
import io
import base64
import numpy as np

def dumbbell(data, title=None, xlabel=None, ylabel=None, color_start='blue', color_end='red', grid='true', legend='false'):
    """
    Create a dumbbell plot (range comparison) from data.

    See: https://matplotlib.org/stable/gallery/lines_bars_and_markers/timeline.html

    This example function is provided as-is without any representation of accuracy.

    Args:
        data (list[list]): Input data (Labels, Start, End).
        title (str, optional): Chart title. Default is None.
        xlabel (str, optional): Label for X-axis. Default is None.
        ylabel (str, optional): Label for Y-axis. Default is None.
        color_start (str, optional): Start color. Valid options: Blue, Black, Green. Default is 'blue'.
        color_end (str, optional): End color. Valid options: Red, Orange, Cyan. Default is 'red'.
        grid (str, optional): Show grid lines. Valid options: True, False. Default is 'true'.
        legend (str, optional): Show legend. Valid options: True, False. Default is 'false'.

    Returns:
        object: Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).
    """
    def to2d(x):
        return [[x]] if not isinstance(x, list) else x

    try:
        data = to2d(data)

        if not isinstance(data, list) or len(data) < 1:
            return "Error: Data must be a non-empty list"

        # Extract labels, start and end values
        labels = []
        start_vals = []
        end_vals = []
        for row in data:
            if not isinstance(row, list) or len(row) < 3:
                continue
            try:
                labels.append(str(row[0]))
                start_vals.append(float(row[1]))
                end_vals.append(float(row[2]))
            except (ValueError, TypeError):
                continue

        if len(labels) == 0 or len(start_vals) == 0 or len(end_vals) == 0:
            return "Error: No valid data rows found (need 3 columns: Label, Start, End)"

        # Create figure
        fig, ax = plt.subplots(figsize=(8, 6))

        # Create dumbbell plot
        y_pos = np.arange(len(labels))

        # Draw lines connecting start and end
        for i in range(len(labels)):
            ax.plot([start_vals[i], end_vals[i]], [i, i], 'k-', linewidth=2, alpha=0.5)

        # Draw start and end points
        ax.scatter(start_vals, y_pos, color=color_start, s=100, zorder=3, label='Start')
        ax.scatter(end_vals, y_pos, color=color_end, s=100, zorder=3, label='End')

        # Set labels
        ax.set_yticks(y_pos)
        ax.set_yticklabels(labels)

        if title:
            ax.set_title(title)
        if xlabel:
            ax.set_xlabel(xlabel)
        if ylabel:
            ax.set_ylabel(ylabel)

        # Handle grid
        if grid == "true":
            ax.grid(axis='x', alpha=0.3)

        # Handle legend
        if legend == "true":
            ax.legend(loc="best")

        plt.tight_layout()

        if IS_PYODIDE:
            buf = io.BytesIO()
            plt.savefig(buf, format='png', bbox_inches='tight')
            plt.close(fig)
            buf.seek(0)
            img_base64 = base64.b64encode(buf.read()).decode('utf-8')
        else:
            return fig
    except Exception as e:
        return f"Error: {str(e)}"

Online Calculator

data *

Input data (Labels, Start, End).

title

Chart title.

xlabel

Label for X-axis.

ylabel

Label for Y-axis.

color_start Optional Blue Black Green

Start color.

color_end Optional Red Orange Cyan

End color.

grid Optional True False

Show grid lines.

legend Optional True False

Show legend.

---

FUNNEL

Create a funnel chart for stages in a process.

Excel Usage

=FUNNEL(data, title, color_map, values, legend)

• data (list[list], required): Input data (Labels, Values).
• title (str, optional, default: null): Chart title.
• color_map (str, optional, default: “viridis”): Color map for stages.
• values (str, optional, default: “true”): Show numeric values.
• legend (str, optional, default: “false”): Show legend.

Returns (object): Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).

Example 1: Simple funnel chart with 4 stages

Inputs:

data
Awareness	1000
Interest	600
Consideration	300
Purchase	100

Excel formula:

=FUNNEL({"Awareness",1000;"Interest",600;"Consideration",300;"Purchase",100})

Expected output:

"chart"

Example 2: Funnel chart with title and values

Inputs:

data		title	values
Stage 1	500	Sales Funnel	true
Stage 2	400
Stage 3	200

Excel formula:

=FUNNEL({"Stage 1",500;"Stage 2",400;"Stage 3",200}, "Sales Funnel", "true")

Expected output:

"chart"

Example 3: Funnel with plasma colormap

Inputs:

data		color_map
Top	800	plasma
Middle	500
Bottom	200

Excel formula:

=FUNNEL({"Top",800;"Middle",500;"Bottom",200}, "plasma")

Expected output:

"chart"

Example 4: Funnel chart with legend

Inputs:

data		legend	values
Lead	1200	true	true
Qualified	800
Closed	300

Excel formula:

=FUNNEL({"Lead",1200;"Qualified",800;"Closed",300}, "true", "true")

Expected output:

"chart"

Python Code

Show Code

import sys
import matplotlib
IS_PYODIDE = sys.platform == "emscripten"
if IS_PYODIDE:
    matplotlib.use('Agg')
import matplotlib.pyplot as plt
import io
import base64
import numpy as np

def funnel(data, title=None, color_map='viridis', values='true', legend='false'):
    """
    Create a funnel chart for stages in a process.

    See: https://matplotlib.org/stable/gallery/lines_bars_and_markers/barh.html

    This example function is provided as-is without any representation of accuracy.

    Args:
        data (list[list]): Input data (Labels, Values).
        title (str, optional): Chart title. Default is None.
        color_map (str, optional): Color map for stages. Valid options: Viridis, Plasma, Inferno, Magma, Cividis. Default is 'viridis'.
        values (str, optional): Show numeric values. Valid options: True, False. Default is 'true'.
        legend (str, optional): Show legend. Valid options: True, False. Default is 'false'.

    Returns:
        object: Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).
    """
    def to2d(x):
        return [[x]] if not isinstance(x, list) else x

    try:
        data = to2d(data)

        if not isinstance(data, list) or len(data) < 1:
            return "Error: Data must be a non-empty list"

        # Extract labels and values
        labels = []
        vals = []
        for row in data:
            if not isinstance(row, list) or len(row) < 2:
                continue
            try:
                labels.append(str(row[0]))
                vals.append(float(row[1]))
            except (ValueError, TypeError):
                continue

        if len(labels) == 0 or len(vals) == 0:
            return "Error: No valid data rows found"

        if any(v < 0 for v in vals):
            return "Error: Values must be non-negative"

        # Create figure
        fig, ax = plt.subplots(figsize=(8, 6))

        # Create funnel using horizontal bars centered
        y_pos = np.arange(len(labels))
        colors_list = plt.cm.get_cmap(color_map)(np.linspace(0, 1, len(vals)))

        # Center the bars
        max_val = max(vals) if vals else 1
        left_edges = [(max_val - v) / 2 for v in vals]

        bars = ax.barh(y_pos, vals, left=left_edges, color=colors_list, edgecolor='black')

        # Add value labels if requested
        if values == "true":
            for i, (bar, val) in enumerate(zip(bars, vals)):
                ax.text(max_val / 2, i, f'{val}', ha='center', va='center', fontweight='bold')

        # Set labels
        ax.set_yticks(y_pos)
        ax.set_yticklabels(labels)
        ax.invert_yaxis()  # Top to bottom

        if title:
            ax.set_title(title)

        # Handle legend
        if legend == "true":
            ax.legend(labels, loc="best")

        # Remove x-axis for cleaner look
        ax.set_xticks([])
        ax.spines['top'].set_visible(False)
        ax.spines['right'].set_visible(False)
        ax.spines['bottom'].set_visible(False)

        plt.tight_layout()

        if IS_PYODIDE:
            buf = io.BytesIO()
            plt.savefig(buf, format='png', bbox_inches='tight')
            plt.close(fig)
            buf.seek(0)
            img_base64 = base64.b64encode(buf.read()).decode('utf-8')
        else:
            return fig
    except Exception as e:
        return f"Error: {str(e)}"

Online Calculator

data *

Input data (Labels, Values).

title

Chart title.

color_map Optional Viridis Plasma Inferno Magma Cividis

Color map for stages.

values Optional True False

Show numeric values.

legend Optional True False

Show legend.

---

PARETO_CHART

Create a Pareto chart (bar chart + cumulative line).

Excel Usage

=PARETO_CHART(data, title, xlabel, ylabel, color_bar, color_line, legend)

• data (list[list], required): Input data (Labels, Values).
• title (str, optional, default: null): Chart title.
• xlabel (str, optional, default: null): Label for X-axis.
• ylabel (str, optional, default: null): Label for Y-axis.
• color_bar (str, optional, default: “blue”): Bar color.
• color_line (str, optional, default: “red”): Line color.
• legend (str, optional, default: “false”): Show legend.

Returns (object): Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).

Example 1: Simple Pareto chart

Inputs:

data
Defect A	50
Defect B	30
Defect C	15
Defect D	5

Excel formula:

=PARETO_CHART({"Defect A",50;"Defect B",30;"Defect C",15;"Defect D",5})

Expected output:

"chart"

Example 2: Pareto chart with custom labels

Inputs:

data		title	xlabel	ylabel
Issue 1	100	Defect Analysis	Defect Type	Count
Issue 2	80
Issue 3	40
Issue 4	20

Excel formula:

=PARETO_CHART({"Issue 1",100;"Issue 2",80;"Issue 3",40;"Issue 4",20}, "Defect Analysis", "Defect Type", "Count")

Expected output:

"chart"

Example 3: Pareto with custom colors

Inputs:

data		color_bar	color_line
Cat A	70	green	yellow
Cat B	50
Cat C	30

Excel formula:

=PARETO_CHART({"Cat A",70;"Cat B",50;"Cat C",30}, "green", "yellow")

Expected output:

"chart"

Example 4: Pareto chart with legend

Inputs:

data		legend
Problem 1	200	true
Problem 2	150
Problem 3	100
Problem 4	50

Excel formula:

=PARETO_CHART({"Problem 1",200;"Problem 2",150;"Problem 3",100;"Problem 4",50}, "true")

Expected output:

"chart"

Python Code

Show Code

import sys
import matplotlib
IS_PYODIDE = sys.platform == "emscripten"
if IS_PYODIDE:
    matplotlib.use('Agg')
import matplotlib.pyplot as plt
import io
import base64
import numpy as np
from matplotlib.patches import Patch
from matplotlib.lines import Line2D

def pareto_chart(data, title=None, xlabel=None, ylabel=None, color_bar='blue', color_line='red', legend='false'):
    """
    Create a Pareto chart (bar chart + cumulative line).

    See: https://matplotlib.org/stable/gallery/showcase/pareto_chart.html

    This example function is provided as-is without any representation of accuracy.

    Args:
        data (list[list]): Input data (Labels, Values).
        title (str, optional): Chart title. Default is None.
        xlabel (str, optional): Label for X-axis. Default is None.
        ylabel (str, optional): Label for Y-axis. Default is None.
        color_bar (str, optional): Bar color. Valid options: Blue, Green, Cyan. Default is 'blue'.
        color_line (str, optional): Line color. Valid options: Red, Yellow, Magenta. Default is 'red'.
        legend (str, optional): Show legend. Valid options: True, False. Default is 'false'.

    Returns:
        object: Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).
    """
    def to2d(x):
        return [[x]] if not isinstance(x, list) else x

    try:
        data = to2d(data)

        if not isinstance(data, list) or len(data) < 1:
            return "Error: Data must be a non-empty list"

        # Extract labels and values
        labels = []
        values = []
        for row in data:
            if not isinstance(row, list) or len(row) < 2:
                continue
            try:
                labels.append(str(row[0]))
                values.append(float(row[1]))
            except (ValueError, TypeError):
                continue

        if len(labels) == 0 or len(values) == 0:
            return "Error: No valid data rows found"

        if any(v < 0 for v in values):
            return "Error: Values must be non-negative"

        # Sort by values descending
        sorted_pairs = sorted(zip(values, labels), reverse=True)
        values = [p[0] for p in sorted_pairs]
        labels = [p[1] for p in sorted_pairs]

        # Calculate cumulative percentage
        total = sum(values)
        if total == 0:
            return "Error: Total value is zero"

        cumulative = np.cumsum(values)
        cumulative_percent = cumulative / total * 100

        # Create figure with two y-axes
        fig, ax1 = plt.subplots(figsize=(10, 6))

        # Bar chart
        x_pos = np.arange(len(labels))
        ax1.bar(x_pos, values, color=color_bar, alpha=0.7, edgecolor='black')
        ax1.set_xlabel(xlabel if xlabel else 'Categories')
        ax1.set_ylabel(ylabel if ylabel else 'Frequency', color=color_bar)
        ax1.tick_params(axis='y', labelcolor=color_bar)
        ax1.set_xticks(x_pos)
        ax1.set_xticklabels(labels, rotation=45, ha='right')

        # Line chart for cumulative percentage
        ax2 = ax1.twinx()
        ax2.plot(x_pos, cumulative_percent, color=color_line, marker='o', linewidth=2)
        ax2.set_ylabel('Cumulative Percentage (%)', color=color_line)
        ax2.tick_params(axis='y', labelcolor=color_line)
        ax2.set_ylim([0, 105])
        ax2.axhline(y=80, color='gray', linestyle='--', linewidth=1)

        if title:
            ax1.set_title(title)

        # Handle legend
        if legend == "true":
            legend_elements = [
                Patch(facecolor=color_bar, label='Frequency'),
                Line2D([0], [0], color=color_line, marker='o', label='Cumulative %')
            ]
            ax1.legend(handles=legend_elements, loc="upper left")

        plt.tight_layout()

        if IS_PYODIDE:
            buf = io.BytesIO()
            plt.savefig(buf, format='png', bbox_inches='tight')
            plt.close(fig)
            buf.seek(0)
            img_base64 = base64.b64encode(buf.read()).decode('utf-8')
        else:
            return fig
    except Exception as e:
        return f"Error: {str(e)}"

Online Calculator

data *

Input data (Labels, Values).

title

Chart title.

xlabel

Label for X-axis.

ylabel

Label for Y-axis.

color_bar Optional Blue Green Cyan

Bar color.

color_line Optional Red Yellow Magenta

Line color.

legend Optional True False

Show legend.

---

SLOPE

Create a slope chart for comparing paired changes across categories.

Excel Usage

=SLOPE(data, labels, title, color_up, color_down, legend)

• data (list[list], required): Input data (Labels, Point1, Point2).
• labels (list[list], required): Labels for the two points.
• title (str, optional, default: null): Chart title.
• color_up (str, optional, default: “green”): Increase color.
• color_down (str, optional, default: “red”): Decrease color.
• legend (str, optional, default: “false”): Show legend.

Returns (object): Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).

Example 1: Simple slope chart

Inputs:

data			labels
Product A	20	35	Before	After
Product B	30	25
Product C	15	40

Excel formula:

=SLOPE({"Product A",20,35;"Product B",30,25;"Product C",15,40}, {"Before","After"})

Expected output:

"chart"

Example 2: Slope chart with title

Inputs:

data			labels		title
Team A	100	150	Q1	Q2	Quarterly Comparison
Team B	120	110
Team C	90	140

Excel formula:

=SLOPE({"Team A",100,150;"Team B",120,110;"Team C",90,140}, {"Q1","Q2"}, "Quarterly Comparison")

Expected output:

"chart"

Example 3: Slope chart with custom colors

Inputs:

data			labels		color_up	color_down
Cat 1	50	80	Start	End	blue	orange
Cat 2	70	60
Cat 3	40	90

Excel formula:

=SLOPE({"Cat 1",50,80;"Cat 2",70,60;"Cat 3",40,90}, {"Start","End"}, "blue", "orange")

Expected output:

"chart"

Example 4: Slope chart with legend

Inputs:

data			labels		legend
Item 1	10	20	2023	2024	true
Item 2	25	15
Item 3	30	35

Excel formula:

=SLOPE({"Item 1",10,20;"Item 2",25,15;"Item 3",30,35}, {2023,2024}, "true")

Expected output:

"chart"

Python Code

Show Code

import sys
import matplotlib
IS_PYODIDE = sys.platform == "emscripten"
if IS_PYODIDE:
    matplotlib.use('Agg')
import matplotlib.pyplot as plt
import io
import base64
import numpy as np
from matplotlib.lines import Line2D

def slope(data, labels, title=None, color_up='green', color_down='red', legend='false'):
    """
    Create a slope chart for comparing paired changes across categories.

    See: https://matplotlib.org/stable/gallery/lines_bars_and_markers/slope_chart.html

    This example function is provided as-is without any representation of accuracy.

    Args:
        data (list[list]): Input data (Labels, Point1, Point2).
        labels (list[list]): Labels for the two points.
        title (str, optional): Chart title. Default is None.
        color_up (str, optional): Increase color. Valid options: Green, Blue. Default is 'green'.
        color_down (str, optional): Decrease color. Valid options: Red, Orange. Default is 'red'.
        legend (str, optional): Show legend. Valid options: True, False. Default is 'false'.

    Returns:
        object: Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).
    """
    def to2d(x):
        return [[x]] if not isinstance(x, list) else x

    try:
        data = to2d(data)
        labels_2d = to2d(labels)

        if not isinstance(data, list) or len(data) < 1:
            return "Error: Data must be a non-empty list"

        # Extract category labels and point values
        categories = []
        point_one = []
        point_two = []
        for row in data:
            if not isinstance(row, list) or len(row) < 3:
                continue
            try:
                categories.append(str(row[0]))
                point_one.append(float(row[1]))
                point_two.append(float(row[2]))
            except (ValueError, TypeError):
                continue

        if len(categories) == 0 or len(point_one) == 0 or len(point_two) == 0:
            return "Error: No valid data rows found (need 3 columns: Label, Point1, Point2)"

        # Extract point labels
        point_labels = ['Point 1', 'Point 2']
        if isinstance(labels_2d, list) and len(labels_2d) > 0:
            if isinstance(labels_2d[0], list) and len(labels_2d[0]) >= 2:
                point_labels = [str(labels_2d[0][0]), str(labels_2d[0][1])]
            elif len(labels_2d) >= 2:
                point_labels = [str(labels_2d[0]), str(labels_2d[1])]

        # Create figure
        fig, ax = plt.subplots(figsize=(8, 8))

        # Draw slopes
        for i in range(len(categories)):
            # Determine color based on slope direction
            if point_two[i] > point_one[i]:
                color = color_up
            elif point_two[i] < point_one[i]:
                color = color_down
            else:
                color = 'gray'

            # Draw line
            ax.plot([0, 1], [point_one[i], point_two[i]], '-o', color=color, linewidth=2, markersize=8)

            # Add category labels
            ax.text(-0.05, point_one[i], categories[i], ha='right', va='center', fontsize=9)
            ax.text(1.05, point_two[i], categories[i], ha='left', va='center', fontsize=9)

        # Set x-axis labels
        ax.set_xticks([0, 1])
        ax.set_xticklabels(point_labels, fontsize=12, fontweight='bold')
        ax.set_xlim(-0.2, 1.2)

        # Remove y-axis
        ax.set_yticks([])

        if title:
            ax.set_title(title)

        # Handle legend
        if legend == "true":
            legend_elements = [
                Line2D([0], [0], color=color_up, linewidth=2, label='Increase'),
                Line2D([0], [0], color=color_down, linewidth=2, label='Decrease')
            ]
            ax.legend(handles=legend_elements, loc="best")

        # Clean up spines
        ax.spines['top'].set_visible(False)
        ax.spines['right'].set_visible(False)
        ax.spines['left'].set_visible(False)
        ax.spines['bottom'].set_visible(False)

        plt.tight_layout()

        if IS_PYODIDE:
            buf = io.BytesIO()
            plt.savefig(buf, format='png', bbox_inches='tight')
            plt.close(fig)
            buf.seek(0)
            img_base64 = base64.b64encode(buf.read()).decode('utf-8')
        else:
            return fig
    except Exception as e:
        return f"Error: {str(e)}"

Online Calculator

data *

Input data (Labels, Point1, Point2).

labels *

Labels for the two points.

title

Chart title.

color_up Optional Green Blue

Increase color.

color_down Optional Red Orange

Decrease color.

legend Optional True False

Show legend.

---

STEM

Create a stem/lollipop plot from data.

Excel Usage

=STEM(data, title, xlabel, ylabel, plot_color, stem_orientation, bottom, legend)

• data (list[list], required): Input data.
• title (str, optional, default: null): Chart title.
• xlabel (str, optional, default: null): Label for X-axis.
• ylabel (str, optional, default: null): Label for Y-axis.
• plot_color (str, optional, default: null): Stem color.
• stem_orientation (str, optional, default: “v”): Orientation (‘v’ or ‘h’).
• bottom (float, optional, default: 0): Baseline position.
• legend (str, optional, default: “false”): Show legend.

Returns (object): Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).

Example 1: Simple vertical stem plot

Inputs:

data
1	10
2	15
3	7
4	20
5	12

Excel formula:

=STEM({1,10;2,15;3,7;4,20;5,12})

Expected output:

"chart"

Example 2: Horizontal stem plot with labels

Inputs:

data		stem_orientation	title	xlabel	ylabel
1	5	h	Horizontal Stem	Values	Categories
2	8
3	3
4	12

Excel formula:

=STEM({1,5;2,8;3,3;4,12}, "h", "Horizontal Stem", "Values", "Categories")

Expected output:

"chart"

Example 3: Colored stem plot with custom baseline

Inputs:

data		plot_color	bottom
1	-2	red	0
2	3
3	-1
4	5

Excel formula:

=STEM({1,-2;2,3;3,-1;4,5}, "red", 0)

Expected output:

"chart"

Example 4: Stem plot with legend

Inputs:

data		legend	plot_color
0	0	true	green
1	1
2	4
3	9

Excel formula:

=STEM({0,0;1,1;2,4;3,9}, "true", "green")

Expected output:

"chart"

Python Code

Show Code

import sys
import matplotlib
IS_PYODIDE = sys.platform == "emscripten"
if IS_PYODIDE:
    matplotlib.use('Agg')
import matplotlib.pyplot as plt
import io
import base64
import numpy as np

def stem(data, title=None, xlabel=None, ylabel=None, plot_color=None, stem_orientation='v', bottom=0, legend='false'):
    """
    Create a stem/lollipop plot from data.

    See: https://matplotlib.org/stable/api/_as_gen/matplotlib.pyplot.stem.html

    This example function is provided as-is without any representation of accuracy.

    Args:
        data (list[list]): Input data.
        title (str, optional): Chart title. Default is None.
        xlabel (str, optional): Label for X-axis. Default is None.
        ylabel (str, optional): Label for Y-axis. Default is None.
        plot_color (str, optional): Stem color. Valid options: Blue, Green, Red, Cyan, Magenta, Yellow, Black, White. Default is None.
        stem_orientation (str, optional): Orientation ('v' or 'h'). Valid options: Vertical, Horizontal. Default is 'v'.
        bottom (float, optional): Baseline position. Default is 0.
        legend (str, optional): Show legend. Valid options: True, False. Default is 'false'.

    Returns:
        object: Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).
    """
    def to2d(x):
        return [[x]] if not isinstance(x, list) else x

    try:
        data = to2d(data)

        if not isinstance(data, list) or len(data) < 1:
            return "Error: Data must be a non-empty list"

        # Extract x and y values
        x_vals = []
        y_vals = []
        for row in data:
            if not isinstance(row, list) or len(row) < 2:
                continue
            try:
                x_vals.append(float(row[0]))
                y_vals.append(float(row[1]))
            except (ValueError, TypeError):
                continue

        if len(x_vals) == 0 or len(y_vals) == 0:
            return "Error: No valid data rows found"

        # Create figure
        fig, ax = plt.subplots(figsize=(8, 6))

        # Create stem plot
        if stem_orientation == "v":
            markerline, stemlines, baseline = ax.stem(x_vals, y_vals, bottom=bottom)
        else:  # horizontal
            markerline, stemlines, baseline = ax.stem(y_vals, x_vals, bottom=bottom, orientation='horizontal')

        # Set color if specified
        if plot_color:
            markerline.set_color(plot_color)
            stemlines.set_color(plot_color)

        # Set labels
        if title:
            ax.set_title(title)
        if xlabel:
            ax.set_xlabel(xlabel)
        if ylabel:
            ax.set_ylabel(ylabel)

        # Handle legend
        if legend == "true":
            ax.legend(['Data'], loc="best")

        plt.tight_layout()

        if IS_PYODIDE:
            buf = io.BytesIO()
            plt.savefig(buf, format='png', bbox_inches='tight')
            plt.close(fig)
            buf.seek(0)
            img_base64 = base64.b64encode(buf.read()).decode('utf-8')
        else:
            return fig
    except Exception as e:
        return f"Error: {str(e)}"

Online Calculator

data *

Input data.

title

Chart title.

xlabel

Label for X-axis.

ylabel

Label for Y-axis.

plot_color Optional Blue Green Red Cyan Magenta Yellow Black White

Stem color.

stem_orientation Optional Vertical Horizontal

Orientation ('v' or 'h').

bottom

Baseline position.

legend Optional True False

Show legend.

---

WATERFALL

Create a waterfall chart (change analysis) from data.

Excel Usage

=WATERFALL(data, title, xlabel, ylabel, color_up, color_down, color_total, legend)

• data (list[list], required): Input data (Labels, Changes).
• title (str, optional, default: null): Chart title.
• xlabel (str, optional, default: null): Label for X-axis.
• ylabel (str, optional, default: null): Label for Y-axis.
• color_up (str, optional, default: “green”): Positive color.
• color_down (str, optional, default: “red”): Negative color.
• color_total (str, optional, default: “blue”): Total color.
• legend (str, optional, default: “false”): Show legend.

Returns (object): Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).

Example 1: Simple waterfall chart with mixed changes

Inputs:

data
Start	100
Increase A	50
Decrease B	-30
Increase C	20

Excel formula:

=WATERFALL({"Start",100;"Increase A",50;"Decrease B",-30;"Increase C",20})

Expected output:

"chart"

Example 2: Waterfall chart with labels

Inputs:

data		title	xlabel	ylabel
Q1	1000	Quarterly Performance	Quarter	Revenue
Q2	200
Q3	-150
Q4	300

Excel formula:

=WATERFALL({"Q1",1000;"Q2",200;"Q3",-150;"Q4",300}, "Quarterly Performance", "Quarter", "Revenue")

Expected output:

"chart"

Example 3: Waterfall with custom colors

Inputs:

data		color_up	color_down	color_total
Initial	500	blue	orange	black
Add	100
Subtract	-50

Excel formula:

=WATERFALL({"Initial",500;"Add",100;"Subtract",-50}, "blue", "orange", "black")

Expected output:

"chart"

Example 4: Waterfall chart with legend

Inputs:

data		legend
Base	1000	true
Gain 1	250
Loss 1	-100
Gain 2	150

Excel formula:

=WATERFALL({"Base",1000;"Gain 1",250;"Loss 1",-100;"Gain 2",150}, "true")

Expected output:

"chart"

Python Code

Show Code

import sys
import matplotlib
IS_PYODIDE = sys.platform == "emscripten"
if IS_PYODIDE:
    matplotlib.use('Agg')
import matplotlib.pyplot as plt
import io
import base64
import numpy as np
from matplotlib.patches import Patch

def waterfall(data, title=None, xlabel=None, ylabel=None, color_up='green', color_down='red', color_total='blue', legend='false'):
    """
    Create a waterfall chart (change analysis) from data.

    See: https://matplotlib.org/stable/gallery/lines_bars_and_markers/bar_label_demo.html

    This example function is provided as-is without any representation of accuracy.

    Args:
        data (list[list]): Input data (Labels, Changes).
        title (str, optional): Chart title. Default is None.
        xlabel (str, optional): Label for X-axis. Default is None.
        ylabel (str, optional): Label for Y-axis. Default is None.
        color_up (str, optional): Positive color. Valid options: Green, Blue. Default is 'green'.
        color_down (str, optional): Negative color. Valid options: Red, Orange. Default is 'red'.
        color_total (str, optional): Total color. Valid options: Blue, Black. Default is 'blue'.
        legend (str, optional): Show legend. Valid options: True, False. Default is 'false'.

    Returns:
        object: Matplotlib Figure object (standard Python) or base64 encoded PNG string (Pyodide).
    """
    def to2d(x):
        return [[x]] if not isinstance(x, list) else x

    try:
        data = to2d(data)

        if not isinstance(data, list) or len(data) < 1:
            return "Error: Data must be a non-empty list"

        # Extract labels and values
        labels = []
        values = []
        for row in data:
            if not isinstance(row, list) or len(row) < 2:
                continue
            try:
                labels.append(str(row[0]))
                values.append(float(row[1]))
            except (ValueError, TypeError):
                continue

        if len(labels) == 0 or len(values) == 0:
            return "Error: No valid data rows found"

        # Calculate cumulative values and positions
        cumulative = [0]
        for val in values:
            cumulative.append(cumulative[-1] + val)

        # Create figure
        fig, ax = plt.subplots(figsize=(10, 6))

        # Prepare bars
        x_pos = np.arange(len(labels) + 1)
        colors = []
        bottoms = []
        heights = []

        for i, val in enumerate(values):
            bottoms.append(cumulative[i])
            heights.append(val)
            if val > 0:
                colors.append(color_up)
            elif val < 0:
                colors.append(color_down)
            else:
                colors.append(color_total)

        # Add total bar
        labels.append('Total')
        bottoms.append(0)
        heights.append(cumulative[-1])
        colors.append(color_total)

        # Create bars
        bars = ax.bar(x_pos, heights, bottom=bottoms, color=colors, alpha=0.7, edgecolor='black')

        # Add connecting lines
        for i in range(len(cumulative) - 1):
            ax.plot([i, i+1], [cumulative[i+1], cumulative[i+1]], 'k--', linewidth=0.5)

        # Set labels
        ax.set_xticks(x_pos)
        ax.set_xticklabels(labels, rotation=45, ha='right')

        if title:
            ax.set_title(title)
        if xlabel:
            ax.set_xlabel(xlabel)
        if ylabel:
            ax.set_ylabel(ylabel)

        # Handle legend
        if legend == "true":
            legend_elements = [
                Patch(facecolor=color_up, label='Increase'),
                Patch(facecolor=color_down, label='Decrease'),
                Patch(facecolor=color_total, label='Total')
            ]
            ax.legend(handles=legend_elements, loc="best")

        ax.axhline(y=0, color='black', linewidth=0.8)
        plt.tight_layout()

        if IS_PYODIDE:
            buf = io.BytesIO()
            plt.savefig(buf, format='png', bbox_inches='tight')
            plt.close(fig)
            buf.seek(0)
            img_base64 = base64.b64encode(buf.read()).decode('utf-8')
        else:
            return fig
    except Exception as e:
        return f"Error: {str(e)}"

Online Calculator

data *

Input data (Labels, Changes).

title

Chart title.

xlabel

Label for X-axis.

ylabel

Label for Y-axis.

color_up Optional Green Blue

Positive color.

color_down Optional Red Orange

Negative color.

color_total Optional Blue Black

Total color.

legend Optional True False

Show legend.
